59.97mm 2.36102" High Chrome Steel Ball G60 G40 For Big Bearing

59.97mm 2.36102" High Chrome Steel Ball G60 G40 For Big Bearing
59.97mm 2.36102" High Chrome Steel Ball G60 G40 For Big Bearing

Large Image :  59.97mm 2.36102" High Chrome Steel Ball G60 G40 For Big Bearing

Product Details:
Place of Origin: china
Brand Name: XMEC(OEM,ODM)
Certification: SGS,ISO9001,IAF,CNAS
Model Number: 59.97mm(2.36102")
Payment & Shipping Terms:
Minimum Order Quantity: 900pcs
Price: FOB tianjin port, qingdao port
Packaging Details: Plastic bag+ cardon box+ wooden pallet
Delivery Time: 20-30days
Payment Terms: L/C, T/T

59.97mm 2.36102" High Chrome Steel Ball G60 G40 For Big Bearing

Description
Material: High Chrome Carbon Steel, 100CrSiMn6-4,GCr15SiMn Grade: G60 Or G40
Hardness: HRc 60-67 Application: Wind Turbine Bearing, Slewing Ring Bearing
Surface: Smooth Surface, Polished Finish Properties: Good Size Stability And Anti-abrasion
Free Samples: Can Be Supplied Package: Plastic Bag + Cardboard Box + Wooden Pallet
High Light:

59.97mm High Chrome Steel Ball

,

G60 High Chrome Steel Ball

,

G40 High Chrome Steel Balls

59.97mm(2.36102"),59.94mm To 60.06mm, High Chrome Steel Balls For Big Bearing, G40 Or G60

Introduction


Chromium (GCr15SiMn, 100CrSiMn6-4, SUJ3) steel ball is a kind of high carbon chromium bearing steel with low alloy content. The high-precision chromium steel ball contains chromium and has excellent surface quality and high bearing capacity due to being quenched.Throughout the manufacturing process, statistical process control can ensure tolerance accuracy, good surface finish and consistent high quality.


The full name of bearing steel is rolling bearing steel. It has high compressive strength and anti-fatigue performance, high hardness, high wear resistance and certain toughness, good hardenability, and extremely strict control of sulfur and phosphorus. It is a high-grade high-quality steel. Make cold work mold steel. Specific gravity: 7.81.

GCr15SiMn bearing steel has higher wear resistance and hardenability than GCr15, medium cold working plastic deformation, poor weldability, sensitive to white spot formation, and temper brittleness during heat treatment. Used to manufacture ferrules with wall thickness> 12mm and outer diameter ≥ 250mm; steel balls with a diameter of 50.8-203.2 and rollers with a diameter> 22mm; in addition, it can also be used as other mechanical parts that require high hardness and high wear resistance, such as rolls. Spiral gauge etc.

Chrome steel ball, as the main part of bearing, are being widely used on the application like automotive industry, automobile,  instruments, heavy machinery, engineering machinery and rolling mill machinery. etc.

We mainly produce chromium steel with a size of 7-82.55mm. The main material is high chromium GCR15 or GCR15SiMn.
The ball has high precision, good surface smoothness, standard hardness and excellent wear resistance. Our products have been widely exported to Europe, America, Japan, Korea and so on.


In addition, the company has advanced production equipment and complete testing equipment, including low-speed cold heads, high-speed cold heads, flashing machines, ball mills, grinders and heat treatment devices.

Through comprehensive testing technology, reliable product quality can be further ensured. Through Rockwell instrument, electronic compression tester, optical microscope, metallographic microscope, appearance profiler, laser surface roughness tester, automatic appearance tester and steel ball vibration tester for testing.


Parameter



Ball Diameter Grade Hardness Material
59.97mm(2.36102") G40 or G60 HRc 60-67 GCr15SiMn,100CrSiMn6-4,SUJ3,52100



Product Details


Product Name High Quality Chrome Steel Balls
Size range Ø 59.94 mm – Ø 60.06 mm(GCr15SiMn/SUJ3/100CrMn6 Chrome Steel Balls)
Quality grades G40 or G60 for balls Ø59.94mm to 60.06mm
Hardness

For 60mm group ball,

a minumun core hardness at centre of the ball shall be HRc55.

minumun hardness at surface of the ball shall be HRc60.

minumun hardness at depth of 15% ball diameter shall be HRc58.

Application The High Quality Chrome Steel Balls are mainly applied in slewing ring bearing for wind turbines,such as single/double row ball bearing,single cross roller bearing,three roller bearing, double row angular contact ball bearing.


Grade and Tolerance


Precision / Grade

Ball Diameter Tolerance
Vdws(≤) µm

Deviation from Spherical Form
△Rs(≤) µm

Maximun surface roughness
Ra(≤)µm

Lot diameter variation
Dwl(≤) µm

G40 1 1 0.06 2
G60 1.5 1.5 0.08 3
